2#
發表於 2005-8-1 09:08 PM
| 只看該作者
http://www.26fun.com/bbs/attachm ... 0&checkid=bc7ac
THX Select 2 certified
HDMI (High-Definition Multimedia Interface)Ver 1.1
Dual i.link digital input for DVD-Audio & SACD
YPAO Yamaha Parametric Room Acoustic Optimizer with supplied setup mic
Dolby Digital EX & Pro Logic IIx
DTS 96/24 Bit, DTS-ES Discrete and DTS Neo:6 Processing
Digital ToP-ART and High Current Amplification
7 Channel High Power Amplifier Configuration
Wide Frequency Range For DVD-Audio
DSP Surround Headphone Output (Silent Cinema DSP)
55 surround programmes (79 variations) with SILENT CINEMA and Night Listening mode
192kHz/24 Bit Digital to Analogue Converters
5 Optical, 3 Coaxial Digital Inputs with 2 optical outputs
Front AV input with optical in behind hidden panel
Quad Field Cinema DSP mode
5.1 Channel External Decoder Input
Pure Direct 2ch Mode turns off all unnecessary circuits
Main L/R, Centre, Rear L/R, Rear Centre L/R
Built in RDS FM/AM Tuner
RS-232 Connection
Audio Delay for Adjusting Lip-Sync
Selectable 9-Band Subwoofer Crossover
2 12V Triggers and IR Remote jacks
Up-conversion to component video
3 Zone Multi room
Supplied with a second multi room remote.
Enhanced Colour GUI and setup display.
http://www.26fun.com/bbs/attachm ... 1&checkid=cea20
Minimum RMS Output Power (8 ohms, 20Hz-20kHz, 0.04% THD)
Front Channels 130W +130W
Center Channels 130W
Surround Channels 130W +130W
Surround Back Channels 130W +130W
High Dynamic Power, Low Impedance Drive Capability Yes
http://www.26fun.com/bbs/attachm ... 7&checkid=75e88
Dynamic Power/Channel 8 ohms 165 W
6 ohms 205 W
4 ohms 260 W
2 ohms 340 W
Linear Damping Yes
Damping Factor (8 ohms, 20 Hz-20kHz) 140 (speaker A)
[center]http://www.26fun.com/bbs/attachm ... 1&checkid=95cbc [/center]
Input Sensitivity/ Impedance Phono (MM) 3.5 mV/47 k-ohms
CD 200 mV/47 k-ohms
Frequency Response 10 Hz-100 kHz +0, -3dB
Total Harmonic Distortion (20Hz-20kHz)
CD (Front Sp Out) 0.04%
Signal to Noise Ratio (CD, 250 mV) 100dB
Filter Characteristics
Front, Center, Surround, Surround Back, (Small, fc=) 40, 60, 80, 90, 100, 110, 120
High Pass Filter Variable Crossover 160 and 200 Hz (12 dB/oct.)
Subwoofer (fc=) 40, 60, 80, 90, 100, 110, 120
Low Pass Filter Variable Crossover 160 and 200 Hz (24dB/oct.)
Video Section
Video Signal Level 1 Vp-p/75 ohms
S-Video Signal Level Y 1 Vp-p/75 ohms
C 0.286 Vp-p/75 ohms
Component Video Signal Level Y 1 Vp-p/75 ohms
Pb/Cb, Pr/Cr 0.7 Vp-p/75 ohms
Signal to Noise Ratio 60dB
Monitor Out Frequency Response
Composite/S-Video Signal 5 Hz-10MHz-3 dB
Component Video Signal 5 Hz-60MHz-3 dB
Tuner Section
FM 50dB Quieting Sensitivity (1 KHz, 100% Modulation)
Mono 2microV (17.3 dBf)
Stereo 25microV (39.2 dBf)
FM Selectivity 400 kHz 70 dB
FM Signal to Noise Ratio Mono/Stereo/HD Radio 76/70/80dB
FM Harmonic Distortion (1kHz) Mono/Stereo/HD Radio 0.2/0.3/0.03%
FM Stereo Separation (1kHz) Stereo/HD Radio 42/70 dB
FM Frequency Response Mono/Stereo 20 Hz-15 KHz + 0.5/-2dB
HD Radio 20 Hz-18 KHz + 0.5/-3dB
General
Standby Power Consumption Less than 0.2 W
Dimensions (W x H x D) 17-1/8" x 6-3/4" x 17-14"
Weight 39.7 lbs.
大約售價 HK$ 12000
[ Last edited by DrChik on 2005-8-1 at 09:31 PM ] |
|
